In short: A demo environment behaved differently from production because a Kubernetes CronJob existed only in the production overlay.

The infrastructure repo had little documentation, and the environment names were ambiguous: stage and staging both existed.

An AI agent helped me trace the CronJob, map stage to the demo environment, and identify the two IaC files that needed changing.

The useful part was not that the agent “knew Kubernetes.” It could inspect the repo faster than I could, compare patterns across overlays, and keep the environment-specific details visible while I reviewed the result.

Note: I’ve kept the high-level logic intact, but I’ve altered specific internal names and insights to respect project confidentiality.

I was working with a client that had 5 application repositories and one Kubernetes infrastructure-as-code repo.

The IaC repo managed application deployments, environment config, and operational automation through GitOps. It had very little documentation.

I had changed one of the applications and needed to test the behavior on the demo environment. The change depended on a CronJob called archive_lapsed_memberships.

Locally, I could run the task manually. In production, the CronJob existed. On demo, the behavior never happened.

I am not a Kubernetes specialist. Waiting for the part-time DevOps team would have meant a long turnaround, so I opened the IaC repo in my agent and started asking questions.

Finding the missing CronJob

The first step was locating the CronJob. I did not know whether it lived in the application repo, the GitOps repo, or some older Kubernetes directory.

Finding the CronJob was the easy part. The harder question was whether the demo environment used the same overlay. The repo had both stage and staging, which is not exactly an intention revealing naming scheme.

Once the agent mapped stage to the demo domain, I had enough context to ask for the actual change.

What follows is a redacted chat I had with the agent. You can skip through the transcript sections if you only want the final change.

0:00

can you tell me where the "add archive_lapsed_memberships" cronjob is defined?

0:04 grep
{"pattern":"archive_lapsed_memberships"}
0:04
Found 4 files
gitops/taskhub-core/overlays/prod/timers.yaml
kubernetes/prod-cluster/default/timers.yaml
opslane-bundle.xml
bundle-output.xml
0:08 grep
{"pattern":"archive_lapsed_memberships","path":"gitops/taskhub-core/overlays/prod/timers.yaml","output_mode":"content","-B":5,"-A":5}
0:08
426- imagePullPolicy: Always
427- command:
428- - bundle
429- - exec
430- - rake
431: - taskhub:archive_lapsed_memberships
432- envFrom:
433- - configMapRef:
434- name: env
435- env:
436- - name: APP_MASTER_KEY
0:11 grep
{"pattern":"archive_lapsed_memberships","path":"gitops/taskhub-core/overlays/prod/timers.yaml","output_mode":"content","-B":20}
0:11
411----
412-apiVersion: batch/v1
413-kind: CronJob
414-metadata:
415- name: archive-lapsed-membership
416-spec:
417- suspend: False # Enable when prod
418- schedule: "30 11 *"
419- jobTemplate:
420- spec:
421- template:
422- spec:
423- containers:
424- - name: archive-lapsed-membership
425- image: northstarlabs/taskhub:stable
426- imagePullPolicy: Always
427- command:
428- - bundle
429- - exec
430- - rake
431: - taskhub:archive_lapsed_memberships
0:16

The cronjob is defined in timers.yaml:412-431. It's a Kubernetes CronJob named archive-lapsed-membership that:

  • Runs daily at 11:30 UTC (30 11 *)
  • Is active (not suspended)
  • Executes bundle exec rake taskhub:archive_lapsed_memberships

There's also an older copy at kubernetes/prod-cluster/default/timers.yaml.

Skip to human interaction ↓ Skip to agent conclusions ↓
E Enrico

After locating the cronjob, I wonder if it runs on all stages.

0:38

does it run on all stages?

0:41 grep
{"pattern":"archive_lapsed_memberships","path":"gitops/taskhub-core/overlays"}
0:41
Found 1 fileg
gitops/taskhub-core/overlays/prod/timers.yaml
0:44

No — it only runs in prod. There's no definition for it in any other overlay (e.g., staging).

1:19

what overlays are defined for that app?

1:22 bash
{"command":"ls /home/devnode/dev_workspace/aurora/opslane/gitops/taskhub-core/overlays/","description":"List overlay directories"}
1:24
prod
stage
staging
1:27

Three overlays: prod, stage, and staging.

Skip to human interaction ↓ Skip to agent conclusions ↓
E Enrico

The poor name definition (I dare you to intuitively know what's the difference between stage and staging) drove my next question.

1:46

what's the difference between stage and staging?

1:50 bash
{"command":"ls /home/devnode/dev_workspace/aurora/opslane/gitops/taskhub-core/overlays/stage/","description":"List stage overlay contents"}
1:50 bash
{"command":"ls /home/devnode/dev_workspace/aurora/opslane/gitops/taskhub-core/overlays/staging/","description":"List staging overlay contents"}
1:51
edge-gateway-cm.yaml
settingsmap.yaml
cronjobs
cloud-secrets.enc.yaml
debugkit.yaml
gateway.yaml
manifest.yaml
hostbackupsecret.enc.yaml
patch-service.yaml
blob-sync-job.yaml
appsecret.yaml
taskhub-api-service.yaml
taskhub-hpa.yaml
processor-hpa.yaml
1:51
edge-gateway-cm.yaml
settings.yaml
cronjobs
cloud-secrets.enc.yaml
gateway.yaml
manifest.yaml
hostbackupsecret.enc.yaml
patch-service.yaml
appsecrets.yaml
taskhub-api-service.yaml
taskhub-hpa.yaml
taskhub-oneoff.yaml
processor-hpa.yaml
2:11

They're very similar — both are staging-like overlays with mostly the same files. Let me check the key differences.

Skip tool calls ↓ Skip to human interaction ↓ Skip to agent conclusions ↓
2:13 grep
{"pattern":"namespace|host","path":"/home/devnode/dev_workspace/aurora/opslane/gitops/taskhub-core/overlays/stage/manifest.yaml","output_mode":"content"}
2:13 grep
{"pattern":"namespace|host","path":"/home/devnode/dev_workspace/aurora/opslane/gitops/taskhub-core/overlays/staging/manifest.yaml","output_mode":"content"}
2:13
12:namespace: taskhub-core
2:13
12:namespace: taskhub-core-staging
2:18

The key difference is the namespace:

  • stage → namespace taskhub-core (shares the default namespace)
  • staging → namespace taskhub-core-staging (has its own dedicated namespace)

They appear to be two separate staging environments deployed to different Kubernetes namespaces. The staging overlay looks like a more isolated environment with its own namespace.

Skip to human interaction ↓ Skip to agent conclusions ↓
E Enrico

The agent pointed out some differences in how those overlays were setup but my focus wasn't on refactoring that. Was to understand to which overlay to add the cronjob.

2:29

what domains are linked to those?

2:33 read
{"path":"/home/devnode/dev_workspace/aurora/opslane/gitops/taskhub-core/overlays/stage/gateway.yaml"}
2:33 read
{"path":"/home/devnode/dev_workspace/aurora/opslane/gitops/taskhub-core/overlays/staging/gateway.yaml"}
2:33
10→apiVersion: networking.k8s.io/v1
11→kind: Ingress
12→metadata:
13→ name: taskhub-core-ingress
14→ annotations:
15→ service.beta.kubernetes.io/linode-loadbalancer-default-proxy-protocol: v1
16→ nginx.ingress.kubernetes.io/proxy-body-size: "100m"
17→ nginx.org/client-max-body-size: "100m"
18→ cert-manager.io/cluster-issuer: acme-prod
19→ namespace: default
20→spec:
21→ ingressClassName: nginx
22→ tls:
23→ - hosts:
24→ - demo.taskhub-center.net
25→ - api.demo.taskhub-center.net
26→ secretName: k8s-check-taskhub-center-net
27→ rules:
28→ - host: demo.taskhub-center.net
29→ http:
30→ paths:
31→ - pathType: Prefix
32→ backend:
33→ service:
34→ name: app
35→ port:
36→ number: 3100
37→ path: /
38→ - host: api.demo.taskhub-center.net
39→ http:
40→ paths:
41→ - pathType: Prefix
42→ backend:
43→ service:
44→ name: edge-gateway
45→ port:
46→ number: 8180
47→ path: /
2:33
10→apiVersion: networking.k8s.io/v1
11→kind: Ingress
12→metadata:
13→ name: taskhub-core-staging-ingress
14→ annotations:
15→ service.beta.kubernetes.io/linode-loadbalancer-default-proxy-protocol: v1
16→ nginx.ingress.kubernetes.io/proxy-body-size: "100m"
17→ nginx.org/client-max-body-size: "100m"
18→ cert-manager.io/cluster-issuer: acme-prod
19→spec:
20→ ingressClassName: nginx
21→ tls:
22→ - hosts:
23→ - staging.taskhub-center.net
24→ - api.staging.taskhub-center.net
25→ secretName: k8s-check-taskhub-center-net
26→ rules:
27→ - host: staging.taskhub-center.net
28→ http:
29→ paths:
30→ - pathType: Prefix
31→ backend:
32→ service:
33→ name: app
34→ port:
35→ number: 3100
36→ path: /
37→ - host: api.staging.taskhub-center.net
38→ http:
39→ paths:
40→ - pathType: Prefix
41→ backend:
42→ service:
43→ name: edge-gateway
44→ port:
45→ number: 8180
46→ path: /
2:36
OverlayApp DomainAPI Domain
stagedemo.taskhub-center.netapi.demo.taskhub-center.net
stagingstaging.taskhub-center.netapi.staging.taskhub-center.net

So stage is the "demo" environment and staging is the actual staging environment.

3:10

So the archive_lapsed_memberships cronjob runs in prod but not on demo correct? How can I add it?

3:14

Correct — it only runs in prod. Let me check how cronjobs are set up in the stage overlay.

Skip tool calls ↓ Skip to agent conclusions ↓
3:15 bash
{"command":"ls /home/devnode/dev_workspace/aurora/opslane/gitops/taskhub-core/overlays/stage/cronjobs/","description":"List stage cronjobs directory"}
3:16 bash
{"command":"ls /home/devnode/dev_workspace/aurora/opslane/gitops/taskhub-core/overlays/prod/cronjobs/ 2>/dev/null || echo \"no cronjobs subdirectory in prod\"","description":"Check if prod has cronjobs subdirectory"}
3:17
attach_match_terms.yaml
staff_movement_index.yaml
resend_verification.yaml
manifest.yaml
view_refreshers.yaml
link_scan.yaml
build_summary_refresh.yaml
taskhub_db_backup.yaml
3:17
no cronjobs subdirectory in prod
3:47 read
{"path":"/home/devnode/dev_workspace/aurora/opslane/gitops/taskhub-core/overlays/stage/cronjobs/manifest.yaml"}
3:47
10→apiVersion: kustomize.config.k8s.io/v1beta1
11→kind: Kustomization
12→# metadata:
13→# name: taskhub-core--cronjobs
14→resources:
15→- attach_match_terms.yaml
16→# - scrapers.yaml
17→- build_summary_refresh.yaml
18→- resend_verification.yaml
19→- view_refreshers.yaml
20→- link_scan.yaml
21→- taskhub_db_backup.yaml
22→- staff_movement_index.yaml
3:50

Let me grab an existing cronjob from stage as a template.

Skip tool calls ↓ Skip to agent conclusions ↓
3:50 read
{"path":"/home/devnode/dev_workspace/aurora/opslane/gitops/taskhub-core/overlays/stage/cronjobs/resend_verification.yaml"}
3:50
10→apiVersion: batch/v1
11→kind: CronJob
12→metadata:
13→ name: resend-verification-mails-demo
14→ # namespace: default
15→spec:
16→ suspend: false
17→ schedule: "15 1 *"
18→ concurrencyPolicy: Forbid
19→ jobTemplate:
20→ spec:
21→ template:
22→ spec:
23→ containers:
24→ - name: resend-verification-mails
25→ image: northstarlabs/taskhub:demo
26→ imagePullPolicy: Always
27→ command:
28→ - bundle
29→ - exec
30→ - bin/rails
31→ - runner
32→ - "ResendVerificationMessageJob.perform_later"
33→ envFrom:
34→ - configMapRef:
35→ name: env
36→ env:
37→ - name: APP_SECRET_BASE
38→ valueFrom:
39→ secretKeyRef:
40→ name: app-secrets
41→ key: app_secret_base
42→ - name: APP_MASTER_KEY
43→ valueFrom:
44→ secretKeyRef:
45→ name: app-key
46→ key: demo.key
47→ - name: PRIMARY_DB_URL
48→ valueFrom:
49→ secretKeyRef:
50→ name: sql-url
51→ key: primary_url
52→ optional: false
53→ restartPolicy: OnFailure
54→ imagePullSecrets:
55→ - name: registry-auth
56→
3:54

Now let me check how the prod version looks for the env vars.

Skip tool calls ↓ Skip to agent conclusions ↓
3:54 read
{"path":"/home/devnode/dev_workspace/aurora/opslane/gitops/taskhub-core/overlays/prod/timers.yaml"}
3:54
411→---
412→apiVersion: batch/v1
413→kind: CronJob
414→metadata:
415→ name: archive-lapsed-membership
416→spec:
417→ suspend: False # Enable when prod
418→ schedule: "30 11 *"
419→ jobTemplate:
420→ spec:
421→ template:
422→ spec:
423→ containers:
424→ - name: archive-lapsed-membership
425→ image: northstarlabs/taskhub:stable
426→ imagePullPolicy: Always
427→ command:
428→ - bundle
429→ - exec
430→ - rake
431→ - taskhub:archive_lapsed_memberships
432→ envFrom:
433→ - configMapRef:
434→ name: env
435→ env:
436→ - name: APP_MASTER_KEY
437→ valueFrom:
438→ secretKeyRef:
439→ name: app-key
440→ key: prod.key
441→ optional: false
442→ - name: APP_SECRET_BASE
443→ valueFrom:
444→ secretKeyRef:
445→ name: app-secrets
446→ key: app_secret_base
447→ optional: false
448→ - name: PRIMARY_DB_URL
449→ valueFrom:
450→ secretKeyRef:
451→ name: sql-url
452→ key: primary_url
453→ optional: false
454→ restartPolicy: OnFailure
455→ imagePullSecrets:
456→ - name: registry-auth
457→
458→---
459→apiVersion: batch/v1
460→kind: CronJob
3:58

You need two changes:

  1. Create the cronjob YAML file
  2. Add it to the kustomization
Skip tool calls ↓ Skip to agent conclusions ↓
4:01 write
{"file_path":"/home/devnode/dev_workspace/aurora/opslane/gitops/taskhub-core/overlays/stage/cronjobs/archive_lapsed_memberships.yaml","content":"apiVersion: batch/v1\nkind: CronJob\nmetadata:\n  name: archive-lapsed-membership\nspec:\n  suspend: false\n  schedule: \"30 11 * * *\"\n  concurrencyPolicy: Forbid\n  jobTemplate:\n    spec:\n      template:\n        spec:\n          containers:\n            - name: archive-lapsed-membership\n              image: northstarlabs/taskhub:demo\n              imagePullPolicy: Always\n              command:\n                - bundle\n                - exec\n                - rake\n                - taskhub:archive_lapsed_memberships\n              envFrom:\n                - configMapRef:\n                    name: env\n              env:\n                - name: APP_MASTER_KEY\n                  valueFrom:\n                    secretKeyRef:\n                      name: app-key\n                      key: demo.key\n                      optional: false\n                - name: APP_SECRET_BASE\n                  valueFrom:\n                    secretKeyRef:\n                      name: app-secrets\n                      key: app_secret_base\n                      optional: false\n                - name: PRIMARY_DB_URL\n                  valueFrom:\n                    secretKeyRef:\n                      name: sql-url\n                      key: primary_url\n                      optional: false\n          restartPolicy: OnFailure\n          imagePullSecrets:\n            - name: registry-auth\n"}
4:17
File created successfully at: /home/devnode/dev_workspace/aurora/opslane/gitops/taskhub-core/overlays/stage/cronjobs/archive_lapsed_memberships.yaml
4:21 edit
{"replace_all":false,"file_path":"/home/devnode/dev_workspace/aurora/opslane/gitops/taskhub-core/overlays/stage/cronjobs/manifest.yaml","old_string":"- staff_movement_index.yaml","new_string":"- staff_movement_index.yaml\n- archive_lapsed_memberships.yaml"}
4:27
The file /home/devnode/dev_workspace/aurora/opslane/gitops/taskhub-core/overlays/stage/cronjobs/manifest.yaml has been updated successfully.
4:32

Done. I created archive_lapsed_memberships.yaml and added it to the manifest.yaml.

Key differences from the prod version:

  • Uses image northstarlabs/taskhub:demo (instead of :stable)
  • References demo.key for APP_MASTER_KEY (instead of prod.key)
  • Adds concurrencyPolicy: Forbid (matching the stage convention)

The change

The fix was two files:

  1. Add gitops/taskhub-core/overlays/stage/cronjobs/archive_lapsed_memberships.yaml
  2. Add that file to gitops/taskhub-core/overlays/stage/cronjobs/manifest.yaml

The demo CronJob used the demo image and demo secret:

  • northstarlabs/taskhub:demo instead of northstarlabs/taskhub:stable
  • demo.key instead of prod.key
  • concurrencyPolicy: Forbid, matching the existing stage CronJob convention

In the end I was able to commit the infrastructure-as-code changes and run the same expiration task on demo that production already had.

What I still had to review

I did not blindly commit the generated YAML.

The agent helped identify the shape of the change, but I still had to check:

  • whether stage was really the demo environment
  • whether the image tag matched the environment
  • whether the secret keys were environment-specific
  • whether the CronJob belonged in the stage cronjobs/manifest.yaml
  • whether the schedule made sense for testing

The agent reduced the search space. It did not remove the need to understand what I was changing.

Why this worked

This worked because infrastructure-as-code is still code. The answer was already encoded in file paths, YAML manifests, overlay names, image tags, secret keys, and existing CronJob conventions.

The agent was useful at four things:

  1. finding where a concept was defined
  2. comparing environment overlays
  3. spotting repo conventions from nearby files
  4. turning those conventions into a small patch

That is a good fit for an agent. It is not Kubernetes magic. It is repository navigation plus pattern matching, with a human checking the assumptions.

This conversation happened inside the infrastructure-as-code repository. If you do not have the repo checked out, you can still get a weaker first pass by giving the agent a repomix file of the infrastructure-as-code repo. The workflow is better when the agent can inspect the actual files.

There was another time when I asked the agent to investigate an environment variable used to connect to a Google Drive folder that failed to operate on demo. The agent pointed me to the problem: a typo in the Drive URL caused the feature to fail on demo.

Documenting infrastructure

The same workflow applies beyond one CronJob.

Once the agent had proven useful for a narrow operational question, I used it for a broader one: what is even in this infrastructure repo?

I asked the agent to create an architecture diagram of the infrastructure-as-code repo, then used the response to create a Mermaid chart.

Architecture diagram generated from the infrastructure-as-code repository

Here is the prompt I used. I explicitly asked for all the application names and moving parts I knew about:

0:00

I need to create a comprehensive architecture diagram. Please explore the repository to map out ALL the applications, infrastructure components, and their dependencies/connections.

Specifically, I need to understand:

  1. All Applications and their components:
    • AppA (main app, workers, API gateway)
    • AppB (backend, celery workers, beat)
    • AppC
    • AppD
    • AppE (workers, flower)
    • AppF
    • Any other apps
  1. Databases - which app uses which database:
    • Look at database connection strings, secrets, environment variables
    • Map PostgreSQL clusters to their consuming applications
  1. Message brokers:
    • RabbitMQ - which apps use it
    • Redis - which apps use it (for caching, sessions, or as broker)
  1. External services:
    • S3/Linode storage
    • Google Sheets integrations
    • Slack webhooks
    • Sentry
    • New Relic
    • Any APIs
  1. Internal service communication:
    • Which services talk to each other
    • API gateway routing
    • Internal service URLs
  1. Infrastructure components:
    • Ingress/load balancers
    • Cert-manager
    • ArgoCD
    • OpenSearch/logging
    • Monitoring (Prometheus, Grafana)

Look at:

  • gitops/*/base and overlays for deployments and secrets
  • kubernetes/ manifests
  • helm/ values files
  • argocd/ application definitions

Provide detailed findings about all connections and dependencies.

Closing

Agents are useful in infrastructure-as-code repos when the answer is already somewhere in the repo, but the repo is too undocumented or sprawling to navigate quickly.

They help with search, comparison, and pattern extraction. They can tell you that stage maps to the demo domain, that production has a CronJob missing from demo, and that stage CronJobs use a different image tag and secret key.

They cannot know whether your team intended the job to run on demo. They cannot know whether stage and staging should both exist. They cannot replace reviewing the patch.

For me, that is still useful. The agent turned an undocumented Kubernetes question into a small infrastructure-as-code change I could review.
